SolidWorks Techniques Every Student Should Know for Display States and Appearances

Understanding Display States and Selection Tools

Assignments often require students to show various aspects or versions of the same model. Whether it's to illustrate internal mechanisms, simplify presentations, or apply specific finishes, Display States and selection tools are crucial for efficiency and clarity.

Display States: Why They Matter

Display States allow you to control the visibility, appearance, and display mode of components without changing the actual geometry or suppressing features. This makes it possible to have multiple visual interpretations of the same assembly, useful for presentation, evaluation, and simulation.

Use cases in student assignments:

• Create a "Before and After" view of a mechanism.
• Show only internal components.
• Color-code sections of a machine for clarity.

How to use Display States:

1. Go to the ConfigurationManager tab.
2. Right-click and choose Add Display State.
3. Name the display state based on your objective (e.g., "Exploded View").
4. Adjust visibility, color, and visual style directly in the graphics area.

Display States are then easily referenced in Drawing Sheets, providing clear and structured illustrations without altering the base model.

Bulk Selection Tools: Speed and Precision

When working on large assemblies, manually selecting each component becomes tedious. SolidWorks provides multiple bulk selection options:

• Select All: Instantly grabs every part in an assembly.
• Select Hidden/Suppressed/Internal: Useful for filtering based on visibility or function.
• Select by Color/Size: Especially helpful for parts sharing physical or visual characteristics.

Why it matters for students:

• Assignments often require isolating certain types of components.
• Helps in quickly hiding/showing, editing, or applying appearances.
• Enhances workflow speed for last-minute adjustments.

Advanced Select: Automating the Smart Way

Advanced Select lets you define rules to automatically select components based on mass, material, name, or custom parameters.

Examples:

• Select all aluminum parts.
• Find components with the word "Bracket" in their name.
• Isolate parts over 0.5 kg.

Steps to use Advanced Select:

1. Navigate to Tools > Component Selection > Advanced Select.
2. Create rules using properties (e.g., Mass > 0.5 kg).
3. Save the selection filter for future use.

For students, this is especially useful when needing to apply uniform changes to a subset of parts across large assignments.

Visual Fidelity: Appearances, Materials and Scene Settings

While design functionality is important, the final look of your model significantly influences grades in design and presentation-focused assignments. Understanding the differences and interplay between Materials, Appearances, and Scenes can turn a good model into a visually impressive one.

Applying Appearances vs. Materials

One of the most common student mistakes is assuming Appearance equals Material. While appearances define how something looks (color, reflectivity, texture), materials define how it behaves physically (mass, stress resistance, etc.).

Why it matters:

• Assignments often specify material properties for simulation or analysis.
• Appearances help communicate design intent clearly in presentations.

Steps to apply materials and appearances:

1. Right-click the part or body.
2. Go to Material > Edit Material and choose from the SolidWorks library.
3. Use the Appearances tab to apply color and texture.
4. Drag and drop appearances from the Task Pane or use custom ones.

Setting the Scene: Lighting and Backgrounds

Scenes affect how your model looks when rendered or viewed in RealView.

Options available:

• Predefined environments (e.g., studio, three-point faded).
• Background color or image.
• Light source customization.

Why students should care:

• A good scene can turn a raw model into a presentable, portfolio-worthy render.
• Professors appreciate attention to detail and realism.

Case Study: Mechanical Assembly Visualization

Imagine a design assignment to build and present a planetary gearbox:

Expectations:

• Internal view to show gear motion.
• External shell highlighted separately.
• Color-coded parts (e.g., brass sun gear, steel ring gear).

Steps to impress:

• Use Display States to toggle between shell and internal mechanism.
• Apply realistic materials.
• Create a neutral background scene with proper lighting.

Engineering Efficiency: Using Envelopes and Selection Filters

Envelopes: Function without Physicality

An Envelope in SolidWorks is a component type used for reference only. It appears in the graphics area but doesn’t affect the Bill of Materials (BOM) or physical calculations.

Use cases in assignments:

• Define safety or operational zones.
• Represent a boundary for motion paths.
• Aid in spatial planning and interference checking.

How to create an envelope:

1. Insert a component into the assembly.
2. Right-click > Component Properties.
3. Check the Envelope option.

Selection Filters: Picking with Precision

Selection Filters (activated via shortcut or toolbar) allow users to limit what can be selected.

Options include:

• Faces only
• Edges only
• Vertices only

Why it's important for students:

• Prevents accidental selection and modification.
• Increases modeling speed.
• Makes sketching and feature creation more accurate.

Bringing It All Together: A Workflow That Works

The true power of these tools comes when they're used together to create a streamlined design, analysis, and presentation workflow. Below is a practical order students can follow:

Conclusion: From Average to Exceptional with the Right Tools

Success in SolidWorks assignments isn’t just about modeling accurately—it’s about using the platform’s advanced tools to present, manage, and communicate your design effectively. Display States simplify view control. Appearances and materials boost visual fidelity. Envelopes help plan intelligent assemblies. And selection tools save valuable time when you're racing toward a deadline.

By integrating these features into your daily SolidWorks usage, you'll not only achieve better grades but also gain a deeper understanding of how engineers and designers work in professional settings.
