How to Solve SolidWorks Assignments Using the Shell Tool

Why Shelling is an Important Skill in SolidWorks

The Shell tool creates hollow parts by removing material from the interior of a solid body, leaving a thin wall of a specified thickness.

This feature is essential for:

• Product design: Making lightweight enclosures, bottles, or casings.
• Mechanical components: Reducing weight without compromising strength.
• Manufacturing readiness: Many parts need uniform wall thickness for injection molding.

Assignments that involve Shell are usually designed to test:

• Your understanding of feature-based modeling.
• Ability to combine multiple features (extrude, cut, fillet, etc.) with Shell.
• Accuracy in dimensioning and constraints.
• Awareness of practical design considerations (draft angles, minimum thickness).

How to Approach a SolidWorks Assignment Involving Shell

When given such an assignment, don’t rush to use the Shell tool immediately.

Follow a structured approach:

Step 1: Read the Problem Carefully

Identify:

• The base shape (cube, cylinder, complex profile).
• The faces to remove during shelling.
• The desired wall thickness.
• Any extra features (holes, fillets, ribs, or patterns).

Step 2: Sketch the Base Geometry

Most shell-based assignments start with a solid base. For example, a cuboid block or a cylinder is created using Extrude Boss/Base. Ensure your sketch dimensions are fully defined to avoid future issues.

Step 3: Apply the Shell Feature

Select the faces you want to open (if any) and specify the wall thickness. If the assignment demands multiple shells or variations, experiment with shelling from different faces to compare outcomes.

Step 4: Add Secondary Features

Assignments rarely end with shelling. You may need to:

• Add cutouts for slots or openings.
• Apply fillets/chamfers for smooth edges.
• Include ribs or bosses for reinforcement.

Step 5: Validate the Model

Check thickness with the Measure tool. Use Section View to confirm hollowing. Always cross-check with assignment requirements.

Example Workflow Inspired by the Attached Assignment

Let’s say your assignment is: “Create a hollow box with a wall thickness of 5 mm, open from the top face, and apply fillets to edges.”

Here’s how you would tackle it:

• Sketch & Extrude Base – Draw a rectangle (100 x 80 mm) and extrude it to 60 mm height.
• Apply Shell – Remove the top face, set wall thickness to 5 mm.
• Add Fillets – Apply 10 mm fillet to vertical edges for smoother design.
• Optional Features – Create circular cutouts on side walls for functional detailing.

This mirrors the type of work you’ll often be asked to do in real assignments.

Common Mistakes Students Make with Shell Assignments

While the Shell tool looks straightforward, many students lose marks due to avoidable errors:

• Incorrect wall thickness – forgetting to update after changing base dimensions.
• Removing wrong faces – double-check which face(s) need to be open.
• Over-filleting – applying fillets before shelling sometimes causes errors. Best to shell first, fillet later.
• Ignoring manufacturability – creating walls thinner than feasible for 3D printing or molding.
• Sketch not fully defined – leading to unstable geometry after modifications.

Tips to Excel in SolidWorks Assignments

1. Plan Before Modeling – Sketch workflow on paper before touching SolidWorks.
2. Use Relations Wisely – Fully define sketches with horizontal, vertical, or equal constraints.
3. Build in Stages – Avoid mixing too many features at once; keep your FeatureManager tree organized.
4. Experiment with Shell Options – Try shelling with and without face removal to see differences.
5. Leverage Reference Geometry – Planes and axes help create symmetrical cutouts.
6. Keep Dimensions Parametric – Use equations for easy updates if dimensions change.

Going Beyond the Shell Tool

While shelling is the focus, SolidWorks assignments usually test your ability to combine features intelligently.

For example:

• Patterning: Circular or linear patterns to replicate holes.
• Mirroring: Quickly create symmetric features.
• Drafts: Needed for manufacturability when designing hollow parts.
• Assembly Context: Some shell-based parts may later fit into larger assemblies.

Practical Case Study: Bottle Design Using Shell

A common real-world project is designing a plastic bottle:

1. Create a cylindrical extrude as the base.
2. Add draft angles for manufacturability.
3. Apply Shell, removing the top face.
4. Add threads for the cap using a swept cut.
5. Finish with fillets for ergonomic design.

Such exercises show how a simple shell assignment in SolidWorks translates into professional design work.

How to Write Reports and Document Assignments

Most professors don’t just want the CAD file.

They expect:

• Screenshots of each step (sketch, shell, cut, fillet).
• Explanations of why you chose specific features.
• Technical drawings with dimensions.
• Reflection on challenges faced and how you solved them.

Writing a clear, step-by-step report boosts your marks and shows mastery.

Final Thoughts

SolidWorks assignments—especially those involving Shell—are less about memorizing buttons and more about understanding workflow and intent. Once you learn to break down a problem into manageable steps, you’ll find even the most complex assignments achievable.

Keep practicing, avoid common mistakes, and don’t hesitate to seek solidworks assignment help if you want expert guidance, faster solutions, or simply to learn professional techniques.
