Designing Complex Assembly Assignments with Advanced Mate Techniques in SOLIDWORKS

In SOLIDWORKS, an assembly is a collection of parts and sub-assemblies put together using mates that control their position and motion relative to each other. Assemblies bring designs to life, enabling simulations, movement analysis, and full system validation before a product hits production.

Think of assemblies as digital prototypes—you build them just like you’d build a physical product. Each piece must fit exactly, interact correctly, and obey constraints. Assignments that test your skill in assembling parts often aim to prepare you for real-world mechanical design tasks.

Assembly File Structure and File References

A common struggle students face is understanding the file structure in SOLIDWORKS. When you insert a part into an assembly, SOLIDWORKS maintains a file reference—meaning it always links back to the original part file.

Here’s a basic breakdown:

• .SLDPRT – Part file
• .SLDASM – Assembly file
• .SLDDRW – Drawing file

Example: If you submit an assembly assignment without including referenced part files, your instructor won’t be able to open it properly. Always include all referenced parts. A good practice is to pack and go—a SOLIDWORKS tool that gathers all related files in one folder.

Solving Mates: The Foundation

Mates are the glue of assemblies. You use mates to define how parts interact—whether they touch, rotate, slide, or remain fixed.

Common mate types:

• Coincident – Aligns faces or edges
• Parallel/Perpendicular
• Distance/Angle
• Concentric – Aligns cylindrical features
• Tangent – Makes curved surfaces touch

Understanding these is crucial, but advanced assignments will challenge you to go beyond the basics, which is where advanced mate techniques shine.

Advanced Mate Techniques and Shortcuts

As assignments increase in complexity, the number of parts and mates grow exponentially. That’s where advanced mate techniques and shortcuts come into play.

Case Study: Mate Shortcuts

Suppose you’re working on an assembly with multiple brackets that must align with corresponding holes. Doing this manually is tedious.

Instead:

• Use Alt + Drag to apply smart mates quickly.
• Ctrl + Select similar faces to apply the same mate across components.
• Use the Mate pop-up toolbar that appears automatically when you preselect multiple faces.

These small steps save a ton of time, especially in student assignments where time constraints are tight.

Mate References and Design Library Parts

If you reuse the same parts across assignments (like standard fasteners or frames), you can simplify mating using Mate References.

What are Mate References?

They are pre-defined mating conditions saved within a part. When you drag that part into an assembly, it auto-aligns using the stored references.

Capture Mate References

1. Open the part.
2. Go to Reference Geometry > Mate Reference.
3. Select primary, secondary, and tertiary faces.
4. Save the part.

From now on, that part knows exactly how to mate—no need to redefine it every time.

This technique is perfect for design library parts like:

• Bolts
• Gears
• Hinges
• Support brackets

Multiple Selection Mate References and Modes

Advanced assignments often involve symmetrical components or multiple identical parts. SOLIDWORKS allows you to select multiple components and apply mates in a batch mode.

Use Multiple Selection Mode when:

• Aligning a row of screws with holes
• Placing gears on shafts
• Connecting rails with multiple sliders

You can even switch Mate Mode to Flexible to simulate real-time motion, which is critical in dynamic assemblies.

Driven Mates and Using Misaligned Mates

There are times when mates conflict. For instance, two holes don’t line up perfectly, but you still want them to connect.

Enter Misaligned Mates:

• SOLIDWORKS allows a slight offset by flexing the part or assembly.
• Useful for simulating bolt-hole tolerances or spring connections.

Driven Mates, on the other hand, are calculated based on other mates. For example, if a crank rotates, the follower arm can be driven using an angle mate or a path mate.

In student assignments, understanding when to use driven mates vs. manually setting them can make or break the simulation.

Copying Multiple Components

Sometimes your assignment may require repeating components with the same mates—think clamps on a beam or wheels on a chassis.

Rather than inserting and mating each one from scratch, use Copy with Mates.

Case Study: Copy with Mates

Imagine inserting four identical bushings onto a rotating shaft.

Steps:

1. Right-click the fully mated component.
2. Select Copy with Mates.
3. SOLIDWORKS prompts you to reassign mate references for each new instance.
4. Complete the mating process once for each location.

This feature saves huge amounts of time and reduces errors.

Fixed Components

Every assembly begins with at least one fixed component—usually the base part. Others are float, meaning they move until fully mated.

Be careful:

• Over-constraining a part can create mate errors.
• Accidentally fixing the wrong part can lead to rigid assemblies.

Pro Tip: Right-click any part > Float or Fix depending on your design intent.

Assignments often test your ability to maintain proper degrees of freedom in mechanical systems. Knowing what to fix—and when—can save your grade.

Summary: Inserting and Mating Components

To recap:

1. Insert base component (fixed).
2. Insert additional parts.
3. Use mate references for reused parts.
4. Apply standard or advanced mates.
5. Use shortcuts like Copy with Mates, Mate pop-up toolbar, or Ctrl + Select.
6. Simulate with flexible and misaligned mates if needed.
7. Save and test for interference or motion.

Advanced Mate Features

Now let’s look at some high-level mate features often found in capstone or final-year projects.

• Width Mate: Centers a part between two faces—ideal for aligning shafts or sliders.
• Symmetric Mate: Keeps a part centered between two references, useful for linkages and suspensions.
• Path Mate: Guides a part along a predefined sketch path—used for cams, tracks, or conveyor belts.
• Limit Mate: Restricts motion to a range (e.g., between 0 and 100 mm)—ideal for pistons, drawers, or clamps.
• Gear and Rack Mates: Simulate rotary to linear motion—advanced but invaluable in robotics or automation assignments.

Case Study: Advanced Mate Features in a Robotic Arm Assignment

A student project involved designing a 5-joint robotic arm. Here’s how advanced mates were applied:

• Revolute Joints used Concentric + Limit mates.
• Gripper used Width + Symmetric mates for balance.
• Base Rotation used Gear mates tied to a controller simulation.
• Path mates were used to mimic cable routing around joints.

Understanding and applying these features effectively can make your submission stand out from the crowd.

Profile Center Mate: A Hidden Gem

This lesser-known feature automatically aligns profiles—center to center.

Great for:

• Square or circular profiles
• Pipes, tubes, and rails
• Frame structures

Use Case: Say you need to align multiple rectangular tubes. Instead of choosing faces and edges, use Profile Center Mate and let SOLIDWORKS snap them to the right orientation.
